Replacement wall mounted push-button switches
compatible with all makes of electric garage door operator
Click image to enlarge
Surface mounted pushbutton switch - round
dimensions: 38mm dia x 20mm deep
fixing screws included
our ref: WS01
price £ excl. VAT
Click image to enlarge
Slimline light switch style pushbutton switch
white finish to match domestic light switches,
ideal for installation on door frame or architrave
dimensions: 87mm H x 35mm W x 29mm deep (with surface mounting box)
surface fixing box and screws included
our ref: WS02A
price £ excl. VAT
Click image to enlarge
Light switch style pushbutton switch
white finish to match domestic light switches,
can be flush or surface mounted
dimensions: 87mm H x 87mm W x 27mm deep (with surface mounting box)
surface fixing box and screws included
our ref: WS04
price £ excl. VAT
Click image for details
Domino digital entry keypad Mounted externally on the
doorframe and wired into an electric operator's pushbutton
circuit,
this
device will enable any motorised door to be opened by entering a security PIN number
into the keypad.
(three 'AA' batteries included)
Key operated external switch
Mounted in the door-frame and wired into an electric door operator's
pushbutton circuit, this device enables the door to be controlled
from outside by means of a key.
Supplied with two keys
our
ref: KS01
price £ excl. VAT
Click image to enlarge
External emergency manual release device
A cable operated device that enables the door to be disconnected
from the motor drive from outside in the event of power failure.
Only required where the motorised garage door is the only means of access.
(not required with Seip operators)
Main hole dia: 25mm with two fixing holes spaced 38mm apart
Supplied with fixing screws & two keys
our
ref: EMR01
price £
excl. VAT
Click image to enlarge
Red emergency manual release toggle
As used on older electric operators to enable the door to be disengaged
from the motor drive in the event of power failure.
Supplied with 75cm white nylon cord
our
ref: APL0045
price £
excl. VAT
Click images to enlarge
Courtesy lamp bulbs
for electric operators
24V 10W bayonet courtesy bulb (SBC fitting)
Hormann Ref: 438313
As used on the following garage door operators:
Hormann
Ecostar, Ecomatic, Promatic series 1, Liftronic & Turbo 75, Garador Auto
Expert, Garamatic 7 & 9, also
used
on the Cardale
Steel-Line Uni-Lift roller door control unit.
price: £
each excl. VAT
24 Volt 15 Watt pygmy lamp
(SES/E14 fitting)
As used on the following Seip garage door operators:
APM60, APM80, UK60 & UK80
price: £
each excl. VAT
32.5 Volt SBC lamp
Sommer 32.5 Volt 34 Watt courtesy lamp
As used on Henderson / Sommer Sommer Sprint
& Marathon garage door operators
Sommer Ref: 11010A
price: £
each excl. VAT
45mm SES golf ball tungsten lamp
230V 40W 45mm golf ball tungsten lamp (SES/E14 fitting)
As supplied with the following Seip garage door operators:
A45, A60, M50, C75, C100, RP60A, ST77, TM60, TS75 & TS100
average life: 1000 hours
0 (discontinued - call us for alternatives)
45mm SES frosted golf ball halogen lamp
230V 3.3W
45mm frosted golf ball halogen lamp (SES/E14 fitting)
A+ rated, energy saving long-life upgrade for the following Seip operators:
A45, A60, M50, C75, C100, RP60A, ST77, TM60, TS75 & TS100
average life: 50000 hours
230V 18W
45mm golf ball halogen lamp
(SBC/BA15s fitting)
An energy saving long-life alternative for 230V 25W SBC lamps
average life: 2000 hours
price: £
each excl. VAT
230 Volt 40W & 60W Rough-Service lamp
Discontinued, please call us for details.
Click image to enlarge
Slotted mounting brackets (one
pair)
as supplied
with all Seip operators
dimensions: 225mm x 93mm x 35mm
One pair are included with all Seip operators but extension
brackets will be required if the distance from the top of your door to the
ceiling is greater than 230mm
(Note: if hammered out flat, these brackets can extend the original brackets by up to 275mm)
supplied with M8 nuts, bolts & washers as illustrated
our ref: APL0046
Click image to enlarge
Steel Punched Angle Kit
(two 76cm lengths)
dimensions: 23mm x 23mm x 760mm
supplied with M8 nuts, bolts & washers as illustrated
our ref: APL0047
price per set: £
excl. VAT
Click image to enlarge
'Hockey-stick' door connecting
arm for
horizontally tracked one-piece doors
this item
made by Seip Antriebs Technik but
is also
compatible with most other makes of electric operator
flat steel bar 25mm x 6.3mm,
overall length: 45cm - hole dia.: 8mm
our ref: APL0041
Price: £
excl. VAT
Click image to enlarge
Door connecting bracket for horizontally tracked doors
Includes 4x fixing screws
This item
made by Seip Antriebs Technik but
is also
compatible with most other makes of electric operator
our ref:
PM04107
Price: £
excl. VAT
Click image to enlarge
Door
connecting bracket for Hormann sectional doors
Includes 4x fixing screws
This item
made by Seip Antriebs Technik but
is also
compatible with most other makes of electric operator
our ref:
APL0044
Price: £
excl. VAT
Click image to enlarge
Side latches
with mounting brackets
for use with Securi-Dor AP2000
includes
fixing screws & latch cables.
latch mounting bracket dimensions:
40mm Length x 38mm Width x 21mm Height
our ref: AP2003
price per pair: £ excl. VAT
Click image for details
Securi-Dor AP2000
automatic security locking system This device enables a
remote controlled door opener to securely lock a garage door
automatically after the door has closed using the original manual side
latches.
Fits all one-piece horizontally tracked single or
double width garage doors regardless of make.
