Features & Benefits:
-
Universal Use
Compatible with any garage door opener with electrical connections for
a wired-in push-button control switch
(connects to same terminals as the internal wall control pushbutton)
-
Easy Programming
System is quickly programmed in three simple steps.
-
Tamper Proof
The keypad shuts off for one minute after five wrong entries have
been pressed and cutting the cable to the inside control box or 'shorting'
the wires from the external keypad will not activate the opener (the
decoding is done within the internal control panel which is located inside the garage separately from the keypad)
-
Weatherproof Flip-up Cover
Design protects the unit against the elements.
-
Personalised User Code
A one to six digit code may be chosen to provide up to 1,000,000 possibilities.
-
Back Lighting
Illuminated keypad for easy night-time operation. Additional indicator
light provides verification as keys are pressed.
-
Low Power Warning/Battery Saver
Lights dim to indicate batteries should be replaced soon. Special sleep circuitry
conserves battery life.
-
Instant Stop
After code is entered and garage door opener is activated, the 'enter'
key may be pressed again to stop or reverse the door, without re-entering the code. The
'enter' key remains active for 20 seconds.
-
Additional Push Button
Conveniently located on control box allows door operation from inside garage.
-
Five year
manufacturers warrantee option
click here
to download the manufacturers
warrantee document for details
(requires Adobe PDF reader)
Specifications:
Outside Keypad
Size:
Length 5" (12.5cm); Width 2" (5cm);
Depth .6" (1.5cm).
Cable length: 37cm (to control box)
Inside Control Box Size:
Length 3" (7.5cm); Width 4.5" (11.5cm);
Depth 1.4" (3.5cm).
Materials:
ABS plastic; Elastomeric
silicone keypad.
Electrical Input:
3x Alkaline batteries type AA
(included)
Electrical Output:
1 amp dry contact relay giving a
0.3 – 3.5 second activation.
|
Keypad (outside) |
Click image to enlarge
internal control panel |
|
DOMINO keyless digital entry system
package includes Domino keypad,
control box, three AA batteries,
four #4 x 3/4" screws, and installation instructions. |
|
|
Domino GD1
keyless digital entry system
|
|
|
|
|
