Garador
type 'C'
vertically tracked canopy type doors**
can re-hung
on new horizontally tracked support gear to enable
safe & reliable
remote controlled operation
(**Garador canopy doors from 1999 - 2002) |
| Out with the old, in with the new ! The following
pictures show various stages of our conversion |
|
|
The
original Garador type 'C' vertically tracked mechanism vertical tracks, support arms,
rollers, cables & springs or weights
etc. are removed & discarded |
Garador 'type C' canopy gear with side mounted springs
(these Garador's have one spring housed in a white plastic
vertical tube
mounted on each side of the door behind the timber
frame upright)
Click image to enlarge
 |
Click image to enlarge
 |
 |
 |
|
The original Garador corner plates are removed & discarded |
|
Once
the door is stripped of the original vertically tracked support gear
it is re-installed on new Arcadian
AP100 horizontally tracked support gear |
|
Large steel bracing plates are fitted to the bottom
corners
to accommodate the new mechanism
Click image to enlarge
 |
New
top rollers & weather-strips are fitted
Click image to enlarge
 |
|
After
conversion - the door with its new fully retracting slide-away
mechanism |
|
Click image to enlarge
 |
Click image to enlarge
 |
|
Click image to enlarge
 |
Click image to enlarge
 |
|
Click image to enlarge
 |
Click image to enlarge
 |
before -
on original canopy mechanism
which is not suited to reliable automation |
after -
on new fully retracting slide-away mechanism
(shown with Seip remote controlled electric
operator installed) |
|
Please Note: After conversion to horizontally
tracked operation the door will extend back into the garage
approximately 40cm to 50cm more than it did with the original vertically
tracked canopy mechanism so please check your garage for obstructions
such as an RSJ or gas meter etc. before undertaking this conversion. |
|
|
Once converted,
your existing canopy door will
glide effortlessly back into the garage on
horizontal
tracks
making it suitable for electric operation. |
Click image to enlarge
 |
The
design of the AP100 lifting gear provides maximum
drive-through width at door mirror height
Soft rubber
weather-strips down the timber door jambs keep out draughts
whilst eliminating any risk of damage to your car |
|
Click image to enlarge
A
completed conversion
with a Seip TM60 electric operator fitted |
Click
Here
for details of our
range
of
remote controlled
Electric Operators
 |
Our conversion provides a cost-effective & reliable method
of automating a canopy type door but the
work should only be undertaken by competent D.I.Y. enthusiasts - Fitting
instructions |
|
|
Security
A
remote controlled garage door will be locked automatically
by the electric operator at the top when closed.
Our
optional
Securi-Dor AP2000
patented locking system can be fitted to provide additional
security
by automatically engaging security bolts at the bottom
corners of the
door when closed to provide an unrivalled level of security |
Click image to enlarge
The
Securi-Dor AP2000
actuating arm |
Click image to enlarge
 |
Click image to enlarge
 |
|
The
Securi-Dor latch operating cam and
a pair of cable operated side latches
(Our Ref. AP2003) |
|
Read what our
D.I.Y. customers say !
| I
purchased two Arcadian AP100 door gear kits to convert a pair of Garador canopy doors.
It's good quality gear and you don't need a degree in rocket science to
fit it. Then I ordered two Seip TM60 remote controlled electric
operators. Again, excellent equipment which was straight forward to
fit and is wonderfully effective. I encountered a couple of minor
problems along the way (with my particular installation, not with
the equipment) and a phone call to Nick at Amourelle had it all
sorted in seconds. Amourelle's prompt delivery and customer service
are second to none. It is refreshing to find a company with such
'old fashioned' customer value! - Jeff Vernon; Doncaster, S. Yorks. |
|
I ordered
a Seip electric door opener and an Arcadian door gear conversion kit
for my canopy type garage door late on Thursday evening, the goods
were delivered next day 11.30!! I received plenty of help and
advice. And there can’t be many businesses that say ”If you are
doing the work over the weekend and need help, then just give me a
call on my mobile” All in all a great service.
I. Saunders, Aldershot, Hants. |
Read More Reviews from
Satisfied Customers
Our conversion provides a cost-effective & reliable method of automating a
canopy type door but the
work should only be undertaken by competent D.I.Y. enthusiasts - Fitting
instructions |
